Verification by Error Modeling

Using Testing Techniques in Hardware Verification

By: Katarzyna Radecka, Zeljko Zilic

Write A Review

Hardcover | 30 November 2003

At a Glance

Hardcover
236 Pages

Dimensions(cm)
24.13 x 15.88 x 1.27

Hardcover

$169.00

or 4 interest-free payments of $42.25 with

Ships in 5 to 7 business days

1. DESIGN FLOW Integrated circuit (IC) complexity is steadily increasing. ICs incorporating hundreds of millions of transistors, mega-bit memories, complicated pipelined structures, etc., are now in high demand. For example, Intel Itanium II processor contains more than 200 million transistors, including a 3 MB third level cache. A billion transistor IC was said to be "imminently doable" by Intel fellow J. Crawford at Microprocessor Forum in October 2002 40]. Obviously, designing such complex circuits poses real challenges to engineers. Certainly, no relief comes from the competitive marketplace, with increasing demands for a very narrow window of time (time-to-market) in engineering a ready product. Therefore, a systematic and well-structured approach to designing ICs is a must. Although there are no widely adhered standards for a design flow, most companies have their own established practices, which they follow closely for in-house design processes. In general, however, a typical product cycle includes few milestones. An idea for a new product starts usually from an - depth market analysis of customer needs. Once a window of opportunity is found, product requirements are carefully specified. Ideally, these parameters would not change during the design process. In practice, initial phases of preparing a design specification are susceptible to potential errors, as it is very difficult to grasp all the details in a complex design.
