Robotic Arm Inversion with Python

Modeling and Controlling the SCORBOT ER-V Plus Using Forward and Inverse Kinematics

By: Fernando Duarte

Write A Review

Paperback | 7 November 2025

At a Glance

Paperback
66 Pages

Dimensions(cm)
22.9 x 15.2 x 0.35

Paperback

RRP $80.08

$78.99

or 4 interest-free payments of $19.75 with

Ships in 7 to 10 business days

This book introduces a method for the inversion of a SCORBOT ER-V plus manipulator, aimed at meticulously analyzing the arm's movement from one spatial point to another. To implement this solution, it is necessary to identify only the starting and ending points in space, along with the geometric constraints of the manipulator. The SCORBOT-ER V plus is a straightforward top-bottom robot featuring five revolute joints, recognized for its reliability and safety, particularly in laboratory and training environments. This experiment provides students with practical experience in robotics, automation, and control systems, highlighting the principles related to the operation and causation of various phenomena. The analysis of object motion demonstrated that the output from the Python script closely aligned with the actual measurements obtained from the robotic arm. Differential movement is employed as a technique to analyze and characterize motion at different points of the robot, thereby facilitating the examination of robotic movement over short durations. This book discusses both forward modeling and inverse kinematics within the realm of robotics. The traditional D-H model is applied to create the mathematical framework essential for determining and assessing the position of the end-effector in a 5-Degree-Of-Freedom (5DOF) robot, which will then be used to calculate the necessary joint configurations.
