Offset Reduction Techniques in High-Speed Analog-to-Digital Converters

Preface. List of Symbols and Abbreviations. 1 High-Speed ADC Architectures. 1.1 Introduction. 1.2 The Analog-to-Digital Converter. 1.3 Flash ADCs. 1.4 Two-Step Flash ADCs. 1.5 Folding and Interpolation ADCs. 1.6 Building Blocks of CMOS High-Speed ADCs. 2 Averaging Technique - DC Analysis and Termination. 2.1 Introduction. 2.2 Published Studies on the Averaging Technique. 2.3 Output Voltage and Gain. 2.4 Effect of Mismatches - INL and DNL. 2.5 Averaging in Folding Circuits. 2.6 Considerations About the Yield. 2.7 Termination of the Averaging Network. 3 Averaging Technique - Transient Analysis and Automated Design. 3.1 Introduction. 3.2 Flash ADC Architecture. 3.3 Output Voltage and Gain. 3.4 Effect of Mismatches. 3.5 Design of Averaged Pre-Amplifier Stages in Flash ADCs. 4 Integrated Prototypes using Averaging. 4.1 Introduction. 4.2 7-bit 120 MS/s I/Q flash ADC. 4.3 10-bit 100 MS/s Folding and Interpolation ADC. 5 Offset Cancellation Methods. 5.1 Introduction. 5.2 Offset Cancellation Techniques. 5.3 New Offset Cancellation Technique. 5.4 6-bit 1 GHz Two-Step Subranging ADC. 6 Conclusions. 6.1 Overview of the Research Work. Appendix A Averaging with Piecewise Linear Differential Pairs. A.1 Introduction. A.2 Output Voltage and Gain. A.3 Effect of Mismatches - INL and DNL. Appendix B Mismatches in the Resistors of the Aveaging Network. B.1 Introduction. B.2 Mismatches in Resistors R0. B.3 Mismatches in Resistors R1. Appendix C Averaging in Folding Stages. C.1 Introduction. C.2 Equivalence Between Circular and Infinite Networks. C.3 Output Voltage and Gain. C.4 Effect of Mismatches. References. Index.
